FOAMPRO® F1000
55
©2001 R11.01
PARTS LIST
6.0
Assembly Description
HANDLE
D200 Handle, Fully Assembled
D201 FP100A handle
D202 1/8" air fitting
D301 Trigger
D302 Trigger Spring
D303 Trigger O Ring
D304 Trigger Set Screw
D291 Handle Cover Plate
AIR CYLINDER
D400 Air Cylinder, Assembled
D401 Cylinder Body
D402 Piston
D403 Set Screw
D404 Piston O Ring
D405 Connecting Rod
D406 Bushing
D407 Inside Bushing O Ring
D408 Outside Bushing O Ring
D409 Bushing C Clip
D410 Back Plate
D411 Back Plate O Ring
D412 Back Plate C Clip
D413 Thumbscrew
D414 Cylinder- Handle O Ring
Service Parts D415 Air Cylinder Repair Kit
Service Parts D416 Bushing Repair Kit
D602 O Ring
CARRIER
D500 Carrier (Assembled)
D501 Carrier Body
D502 Attachment Screw
D503R Red "A" Valve Unit
D503B Blue "B" Valve Unit
D504 Filter Screen
D505 Filter Plug
D506 Filter Plug O Ring
D507 Hose Connector
D508 Check Spring
D509 Check Ball
D510 Thumbnut
Service Part D511 Valve O Ring Kit
Service Part D513 Valve Pin Stop
