3.2.3
There are two Filter Screens (D504) in the side of the Carrier (D501). One Filter
Screen is for the “A” Chemical, and the other Filter Screen is for the “B” Chemical.
These Filters are designed to catch any particulate matter that may be present from
getting into the Mix Cartridge (D603). The Filter Screens need to be cleaned peri-
odically.
This procedure can be performed without relieving the pressure on theThis procedure can be performed without relieving the pressure on the
This procedure can be performed without relieving the pressure on theThis procedure can be performed without relieving the pressure on the
This procedure can be performed without relieving the pressure on the
Chemical Flow System, provided that the Red chemical valve (D503R)Chemical Flow System, provided that the Red chemical valve (D503R)
Chemical Flow System, provided that the Red chemical valve (D503R)Chemical Flow System, provided that the Red chemical valve (D503R)
Chemical Flow System, provided that the Red chemical valve (D503R)
and the Blue chemical valve (D503B) remain closed during the entireand the Blue chemical valve (D503B) remain closed during the entire
and the Blue chemical valve (D503B) remain closed during the entireand the Blue chemical valve (D503B) remain closed during the entire
and the Blue chemical valve (D503B) remain closed during the entire
procedure. procedure.
procedure. procedure.
procedure.
(See diagram 42A for location of these valves)(See diagram 42A for location of these valves)
(See diagram 42A for location of these valves)(See diagram 42A for location of these valves)
(See diagram 42A for location of these valves)
To clean the Filter Screens:
1 | Remove the Filter Plug (D505).
(See diagram 43A & 43B)(See diagram 43A & 43B)
(See diagram 43A & 43B)(See diagram 43A & 43B)
(See diagram 43A & 43B) The Filter Screen
(D504) is pressed onto the end of the Filter Plug (D505). The Filter Screen can be
rinsed with solvent without removing it from the Filter Plug. If the Filter Screen
(D504) is damaged, it can be pulled off the Filter Plug and replaced by pressing
a new Filter Screen onto the Filter Plug (D505).
2 | Rinse with solvent the opening on the Carrier (D501) that the Filter Screen
Plug (D505) fits into.
3 | Replace the O Ring (D506) on the Filter Plug (D505).
4 | Re-install the Filter Plug and Screen Assembly into the Carrier and tighten.
Diagram 42A
