GM47/GM48 INTEGRATOR’S MANUAL
302
LZT 123 7263 R1C
The maximum length is fixed
17.10 *E2STKE STK Send Short Message
Unsolicited Result Code:
*E2STKE: <coding>, < text_length >, <alpha_id>
The ME passes the <alpha_id> within SEND SHORT MESSAGE
command to the external application, by means of the unsolicited result
code *E2STKE. This informs the external application that the ME is
sending an SMS.
The maximum length is fixed.
<text_length> Description
Integer type (0-240) Value indicating the maximum length of field
<alpha_id>
<alpha_id> Description
String type Field of string type between “”. Coding is according to
EF
AND
as defined in GSM 11.11
<coding> Description
0 Text is coded in unpacked format, using the SMS default 7-bit
coded alphabet, as defined in GSM 03.38 with bit 8 set to 0. It
corresponds to data coding scheme of 8 bit
1 Text is coded in packed format, using the SMS default 7-bit
coded alphabet, packed in 8-bit octets, as defined in GSM
03.38. It corresponds to data coding scheme of 7 bit GSM
default alphabet
<text_length> Description
Integer type (0-240) Value indicating the maximum length of field
<alpha_id>
<alpha_id> Description
String type Field of string type format between “”. Coding is
according to EF
AND
as defined in GSM 11.11
‘FF’ In case that the SIM does not provide the optional alpha
identifier, or this is a null data object, the ME shall give ‘FF’
to indicate “Sending SMS”, so that the external
application is informed
