For details about available characters for the dial format, see Available Values for the Dial Plan Field in
this section.
3. Select [Yes] or [No] for [Call Even If Dial Plan Does Not Match].
• If you select [Yes], the call will be made even if the user dials a phone number that does not match
the dial format in [Dial Plan].
• If you select [No], the call will be made only if the user dials a phone number that matches the dial
format in [Dial Plan].
Note
• For details about configuring these settings by configuration file programming, see "DIAL_PLAN_[1–
8]" and "DIAL_PLAN_NOT_MATCH_ENABLE_[1–8]" in 4.7.1 Call Control Settings.
Available Values for the Dial Plan Field
The following table explains which characters you can use in the dial format, and what the characters mean.
Element
Available Value Description
String 0–9, [, -, ], <, :, >, *, #, !,
S, s, X, x, ., |
You can enter dial plan descriptions using a combination of
the characters listed as available values.
Digit 0–9, *, # Example: "123"
If the dialed phone number is "123", the call is made
immediately.
Wildcard X, x Example: "12xxxxx"
If the dialed phone number is "12" followed by any 5-digit
number, the call is made immediately.
Range [ ] Example: "[123]"
If the dialed phone number is either one of "1", "2", or "3", the
call is made immediately.
Subrange - Example: "[1-5]"
If the dialed phone number is "1", "2", "3", "4", or "5", the call
is made immediately.
• A subrange is only valid for single-digit numbers. For
example, "[4-9]" is valid, but "[12-21]" is invalid.
Repeat . Example: "1."
If the dialed phone number is "1" followed by zero or more
"1"s (e.g., "11", "111"), the call is made.
Substitution <(before):(after)> Example: "<101:9999>"
If the dialed phone number is "101", "101" is replaced by
"9999", and then the call is made immediately.
Timer S, s (second) Example: "1x.S2"
If the dialed phone number begins with "1", the call is made
after a lapse of 2 seconds.
• The number (0–9) followed by "S" or "s" shows the
duration in seconds until the call is made.
Reject ! Example: "123xxx!"
If the dialed phone number is "123" followed by 3 digits, the
call is not made.
Document Version 2010.03.15 Administrator Guide 207
5.3.1 Dial Plan Settings
