Specifi cations
Physical Specifi cations
Size: 5.7” W x 3.2” H x 1.9” D
(14.5 x 8.1 x 4.8 cm)
Weight: 13.6 ozs (.39 kg)
Display: 3.75” diagonal (9.5 cm)
Transfl ective, 256-color display with
backlighting (480 x 320 pixels)
Case: Fully-gasketed, high-impact plastic
alloy, waterproof to IEC
60529 IPX7
Temp. Range: 5°F to 140°F (-15°C to 60°C)
Performance
Battery Life: 5 to 15 hours depending upon the backlight setting
Receiver: Differential-ready 12 parallel channel receiver
Acquisition Times: Approx. 15 seconds (warm start)
Approx. 45 seconds (cold start)
Approx. 5 minutes (First Time/AutoLocate™)
Update Rate: 1/second, continuous
GPS Accuracy: *< 15 meters (49 feet) RMS 95% typical
DGPS (USCG) Accuracy: 3-5 meters (10-16 ft), 95% typical
DGPS (WAAS) Accuracy: 3 meters (10 ft) 95% typical with DGPS corrections
Velocity Accuracy: 0.1 knot RMS steady state
Dynamics: 6g's
* Subject to accuracy degradation to 100m 2DRMS under the U.S. DOD-imposed Selective Availability Program.
Power
Battery: Rechargeable Lithium ion
Source: 11–35V DC
Fuse: 3AG - 1.5 Amp
