Appendix 233
Cellular Radio Module
Functionality HSDPA/UMTS (2100 for Europe, 850/1900 for USA)
GSM/GPRS/EDGE (850, 900, 1800, and 1900)
Mode Dual (GSM)
Internal Antenna Yes
Physical
Dimensions 133.1 mm (L) x 97.7 mm (W) x 16 mm (T)
Thickness with keyboard: 20 mm
Weight Less than 350g (with battery)
Camera Module
Type Main camera: 3 megapixels with auto focus and flash light
Second camera: VGA CMOS imaging sensor
Resolution Photo: 2048 x 1536 (QXGA), 1600 x1200 (UXGA),
1280 x1024 (SXGA), 640 x 480 (VGA), 320 x 240 (QVGA),
160 x120 (QQVGA)
Video: 352 x 288 (CIF), 320 x 240 (QVGA), 176 x144 (QCIF),
128 x 96
Digital Zoom Up to 8x
Connections
I/O Port • HTC ExtUSB
TM
: an 11-pin mini-USB 2.0 and audio jack
in one
(ExtUSB is a proprietary connection interface that is
trademarked by HTC).
• HTC proprietary
16-pin combined port (USB 1.1 host/
VGA and TV Out)
Car Antenna
Connector
Yes
GPS Antenna
Connector
Yes
Audio Stereo earphone/Microphone jack
Wireless
Connections
Bluetooth®, Wi-Fi®
