OnCell G2150I AT Command Set Result Codes, Failure Causes,, and Other Tables
A-8
mandatory information element is missing and/or has a content error (the two cases are
undistinguishable).
Cause No. 97
: “Message type non-existent or not implemented”
This cause indicates that the equipment sending this cause has received a message with a message
type it does not recognize either because this is a message not defined or defined but not
implemented by the equipment sending this cause.
Cause No. 98
: “Message not compatible with short message protocol state”
This cause indicates that the equipment sending this cause has received a message such that the
procedures do not indicate that this is a permissible message to receive while in the
short message transfer state.
Cause No. 99
: “Information element non-existent or not implemented”
This cause indicates that the equipment sending this cause has received a message which includes
unrecognized information elements because the information element identifier is not
defined or it is defined but not implemented by the equipment sending the
cause. However, the information element is not required to be present in the message so that the
equipment sends the cause to process the message.
Cause No. 111
: “Protocol error, unspecified”
This cause is used to report a protocol error event only when no other cause applies.
Cause No. 127
: “Interworking, unspecified”
This cause indicates that there has been interworking with a network which does not provide
causes for actions it takes; thus, the precise cause for a message which is being sent
cannot be determineed. All values other than specified should be treated as error Cause
No 41.
Unsolicited Result Codes
Verbose Result Code Numeric (V0 set) Description
+CALA: < time string>,<index> As verbose Alarm notification
+CBM: <length><pdu> (PDU)
or
+CBM:<sn>,<mid>,<dcs>,<page>,<
pages>… (Text mode)
As verbose Cell Broadcast Message directly
displayed
+CBMI: “BM”,<index> As verbose Cell Broadcast Message stored in
mem at location <index>
+CCCM: <ccm> As verbose Current Call Meter value
+CCED: <values> As verbose
(specific)
Cell Environment Description
indication
+CCWA:<number>,<type>, <class>
[,<alpha>]
As verbose Call Waiting number
+CDS: <fo>, <mr>… (text mode)
or +CDS: <length>,… (PDU)
As verbose SMS status report after sending a
SMS
+CDSI: <mem>,<index> As verbose Incoming SMS Status Report after
sending a SMS, stored in
<mem> (“SR”) at location <index>
+CKEV: <keynb> As verbose Key press or release
