110 Chapter 4
CDMA Measurements - Screens and Control Fields
RF In/Ant Threshold
RF In/Ant
This field selects the Test Set’s RF input.
CAUTION The maximum safe level into the ANT IN connector is
60 mW. Exceeding this level could cause permanent
damage to the Test Set.
Screens on which this field is present
CODE DOM (Code Domain Analyzer): main controls menu
Threshold
Enter the measurement display threshold for making code domain
timing and phase measurements. Walsh channels that have power
levels below the threshold value are not displayed.
Operating Considerations
Querying these measurements for Walsh channels that are below the
threshold level using HP-IB will return a default value of 9e99.
Screens on which this field is present
COD DOM (Code Domain Analyzer): auxiliary controls menu
