MDW 9030P Pocketphone Compatibility
6-9
System 25, System 75, System 85,System 25, System 75, System 85,
System 25, System 75, System 85,System 25, System 75, System 85,
System 25, System 75, System 85,
and DEFINITY Systemsand DEFINITY Systems
and DEFINITY Systemsand DEFINITY Systems
and DEFINITY Systems
■
This phone must be administered as a BIS-22D MERLIN set (Apparatus Code 7315H)
for the following systems:
— System 25
—
System 75—R1V1, R1V2, and R1V3
—
System 85—R2V1, R2V2, R2V3, and R2V4
—
DEFINITY G1 (R1V4)
—
DEFINITY G2—G2.1 and G2.2—(R2V5, R2V6)
—
DEFINITY G3 Version 1 (R1V5)
—
DEFINITY G3 Version 1.1 and Version 2
Native terminal administration is provided in DEFINITY G3 Version 3.
■
To connect the communications system switch and the MDW 9030P Pocketphone, use
the following:
—
An ANN17B Hybrid pack in conjunction with a DS-1 carrier for older communications
system switches that do not accommodate Universal modules (System 85 −R2V1,
R2V2, R2V3, and R2V4)
—
Either a TN762B Hybrid pack or a ZTN79 ATL pack for System 25
—
A TN762B Hybrid pack for newer communications system switches that accommo-
date Universal modules:
■
System 75 − R1V1, R1V2, and R1V3
■
DEFINITY G1 (R1V4)
■
DEFINITY G3 Version 1 (R1V5)
■
DEFINITY G3 Version 1.1 and Version 2
■
DEFINITY G3 Version 3
— Either a TN762B or an ANN17B Hybrid pack for DEFINITY G2 (G2.1 and G2.2),
depending upon the actual hardware configuration.
NOTE:NOTE:
NOTE:NOTE:
NOTE:
For DEFINITY G2.1 and G2.2, General Terminal Administration (GTA) can be used
to set up “custom” set types so that administration can be done using that custom
set type.
■ System 25 users cannot program Recall for use with systems such as Centrex.
■
Only the System Administrator can assign features. Use the following guidelines:
—
Do not assign the following features: Auto Answer, Inspect, Directory, Next, Local,
Call, and Manual Callback Queuing.
—
If programming the Flex DSS or Repertory Dial feature, dial the number to be
recorded and push the button you are assigning to the feature. You will hear 3
short beeps and a dial tone to confirm programming.
—
If you are programming numbers for the Station Speed Dial feature, dial the numbers to
be stored then dial the Personal Speed Dialing code (#20 through #39),
including the #. Listen for a confirmation tone followed by a dial tone.
— It is recommended that you do not use features that require visuals to be updated
while the set is turned off.
— Some features, such as Send All Calls, provide visual indication that the feature is
turned on. Make users aware that if they turn off the handset when using such a
feature, they may forget that the feature is on.
