2 - 4
Step 2. Charge the Battery
The power source for the Dolphin terminal is the 3.7V Li-ion rechargeable battery located under the
battery door on the back panel of the device. See Battery on page 3-12 for additional information on
battery storage, use, and disposal.
Important: Removing the battery from the terminal erases all non-persistent memory. Always place the terminal in
Suspend mode before removing the battery. For information on how to remove the battery from the terminal, see
Replacing the Battery on page 2-15.
Before Initial Use
Dolphin terminals ship with the battery significantly discharged of power. After installing the battery in the
terminal, charge the battery with a Dolphin 70e Black charging peripheral for a minimum of 4 hours for
the standard battery pack or 6 hours for the extended battery pack. When using the 70e-USB Charge/
Communication cable to charge from a 500mA USB port on a host device, charge the battery for a
minimum of 6 hours for the standard battery and 8 hours for the extended battery.
Note: Inadequate source current may interfere with effective battery charging; see Important Charging
Guidelines on page 3-13 for additional information.
We recommend use of Honeywell peripherals, power cables, and power adapters. Use of any non-Honeywell
peripherals, cables, or power adapters may cause damage not covered by the warranty.
Dolphin 70e Black model terminals are designed for use with the following charging devices and cables:
70e-HB, 70e-CB, 70e-EHB, 70e-NB, 70e-MB, 70e-MC, and 70e-USB ADAPTERKIT. See pages 3-2 and
3-3 for additional information on Dolphin 70e Black peripherals and accessories.
Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet
components may cause damage not covered by the warranty.
Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT)
Dolphin 70e Black terminals ship with a USB Charge/Communication Cable and a power adapter with
regional plug adapters. The USB Charge/Communication cable provides two options for charging the
terminal. Use the cable in conjunction with the provided power supply adapter and plug adapter to
charge the terminal from a power outlet (Option 1 on page 2-5) or connect the cable to a high-power
USB port to charge from a host device (Option 2 on page 2-5).
Warning - The terminal shall only be connected to CTIA certified adapters, products that bear the USB-IF logo
or products that have completed the USB-IF compliance program when using the micro USB port as a
charging source.
!
!
!
