8 - 3
• Headset Mode
When a headset is plugged into the Audio Jack, the terminal defaults
to the headset for receiving calls and audio input.
• Hands-Free Mode
The bottom speakers are used as a speaker phone. To switch to speaker phone during a call,
touch on the phone icon in the tile bar at the bottom of the screen, and then select Speaker On.
Important - Do not cover the side microphone with your hand when using the terminal for phone calls.
Both the front and side microphones must be free from obstruction for the noise cancellation feature to
function properly during a handset mode call.
Volume Control
Press the up or down arrow on the Volume Control button on the left side of the device to adjust the
volume of the active speaker, see Volume Control Button on page 3-10.
Using the Dolphin Terminal as a Phone
If your Dolphin model is equipped for voice + data WWAN connectivity, you can use the terminal as a
phone over the cellular networks.
You can initiate a phone call from the Phone app , the People app or the Voice Dialer app .
Using the Phone App to Initiate a Call
Touch the Phone app icon on the Home screen. The Phone app is organized into three tabs:
Phone , Call Log , and Contacts . You can initiate a call from any of the three tabs.
To switch between the tabs, swipe left or right on the screen or select the relevant icon.
Note: With the Phone App open, press the Menu button , and select Settings to manage advanced phone
options (e.g., Voicemail, Call Forwarding, Fixed Dialing Numbers and Internet Call Settings).
Phone
1. Open the Phone app and select the Phone icon if the dialer keypad is not visible.
