3 - 9
Feature Descriptions: Back, Top, and Left Panels
Audio Jack
The audio jack is located under the protective door on the top of the terminal. To access the
jack gently lift the edge of the door and rotate it 90° counterclockwise. The 3.5mm audio jack
supports both speaker (stereo) and microphone (mono) headsets.
Battery
The 3.7V Li-ion rechargeable battery provides the main power for the terminal and is protected
by the battery door. See Battery on page 3-12 for battery specifications, replacement part
numbers, and guidelines for use and disposal.
Battery Door
The battery door protects the battery and any installed SIM and/or memory cards in the
terminal’s battery well. Proper installation of the battery door preserves the environmental
rating of the terminal. For information on how to remove the battery, see Replacing the Battery
on page 2-15.
Note: Do not use the terminal without the battery door installed.
Battery Door Lock
Some Dolphin 70e Black models come equipped with a battery door lock on the back panel.
Slide the lock down toward the IO contacts to release the lock for battery door removal and
battery access. Slide the lock up toward the camera lens to secure the battery door closed and
seal the battery in the terminal. Proper installation of the battery door preserves the
environmental rating of the terminal. For information on how to remove the battery, see
Replacing the Battery on page 2-15.
Battery Latch
All Dolphin 70e Black models come equipped with a battery latch that secures the battery in
the battery well. To remove the battery from the terminal, first pull the latch back away from the
battery. For information on how to remove the battery, see Replacing the Battery on page 2-15.
Battery Retention Strap
Some Dolphin 70e Black models come equipped with a battery retention strap, which in
conjunction with the battery latch secures the battery in the battery well. The retention strap
attaches to battery once the battery is installed in the terminal. Do not pull on the retention
strap while attempting to remove the battery. For information on how to remove the battery,
see Replacing the Battery on page 2-15.
Color Camera
The 5.0-Megapixel Resolution color camera provides easy picture and video capture. The
camera lens and camera flash are located on the back panel of the terminal.
Camera Flash
The camera flash is located on the back panel of the terminal. When used as a Camera Flash
with the terminal’s color camera, the flash is controlled by the camera application.
Image Engine Window
The image engine reads and decodes linear, stacked linear (e.g., PDF417), and 2D matrix bar
code symbologies. The LED aperture for the imaging engine’s LED aimer is contained behind
this window. For more details, see Using the Scan Image Engine on page 4-1.
