222 Appendix
Appendix 223
Phone
Network HSDPA/UMTS: 2100 MHz
HSDPA: Up to 384kbps for upload and 3.6Mbps for
download;
UMTS: Up to 384kbps for upload and download
GSM/GPRS/EDGE: Tri-band (900, 1800, and 1900 Mhz)
(The device will operate on frequencies available from the
cellular network)
Internal Antenna Yes
Physical
Dimensions 107 mm (L) x 55 mm (W) x 15.8 mm (T)
Weight 120 g (with battery)
Camera Module
Type Main Camera: 2 megapixel color CMOS camera
Second Camera: CIF CMOS
Resolution Photo: 1600 x1200 (UXGA), 1280 x 960 (SXGA),
640 x 480 (VGA), 320 x 240 (QVGA), 160 x120 (QQVGA)
Video: 176 x 144 (QCIF), 128 x 96
Digital Zoom Up to 8X
Connections
I/O Port HTC ExtUSB
TM
: 11-pin mini-USB and audio jack in one
Hi-speed USB 2.0
HTC H2Wire support
Wireless
Connections
Bluetooth 2.0
Car Antenna
Connector
External connector for GSM/EDGE
A.1 Specifications
System Information
Processor Qualcomm® 7200 400 MHz
Memory - ROM : 256 MB
- RAM : 128 MB DDR
(Figures are the total ROM and RAM memory available for use and
storage. Since the memory is shared by the Operating System,
applications, and data, the actual available memory is less than what
is written).
Operating System Windows Mobile® 6 Professional
Power
Battery Rechargeable Li-Polymer battery, 1120 mAh
Charging Time 3 hours
Battery Life
(estimates)
Standby time: GSM: Up to 180 hours
UMTS: Up to 250 hours
(Subject to network and phone usage)
Talk time: GSM: Up to 5 hours
UMTS: Up to 3 hours
(Subject to network and phone usage)
Video telephony Up to 1.78 hours
Media playback
time
Up to 4.95 hours (WMV)
Up to 6 hours (WMA)
AC Adapter Voltage range/frequency: 100 - 240V AC, 50/60 Hz
DC output: 5V and 1A
Display
LCD Type 2.6” TFT-LCD with backlight LEDs, touch-sensitive screen
Resolution 240 x 320 with 65,536 colors
Orientation Portrait and Landscape
