Chapter 5 167
CDMA Measurements - Screens and Control Fields
Control Fields for CDMA Measurements
Pwr Intvl
This field determines the length of the data block when measuring
average power. The data block is a time record over which correlated
measurements are computed.
Range: 0.25 to 15.0 ms
Screens on which this field is present
CDMA ANALYZER
Pwr Ref
This Code Domain field determines the reference level from which the
power reading is taken. This value is always 0 dB.
Screens on which this field is present
COD DOM (Code Domain Analyzer, IS-2000): marker controls menu
Pwr Scale – IS-95
The upper subfield is used to select the reference level for power
measurements (relative to the total power of the entire CDMA
channel). The reference is the top line of the screen and defaults to
0dB.
The lower subfield is used to select the display resolution for the power
measurement; 1, 2 or 5 dB per vertical division.
The power scale fields are displayed in the Marker menu when the Main
controls Measurement field is set to Power or Fast Pwr.
Screens on which this field is present
COD DOM (Code Domain Analyzer): marker controls menu
Pwr Scale – IS-2000
This Code Domain field (IS-2000) is used to select the display resolution
for the power measurement: 1, 2 or 5 dB per vertical division
The power scale field is displayed in the Marker menu when the Main
controls Measurement field is set to Power, Fast Pwr,
Power & Noise, Complex Power or FstPwr Sync..
Screens on which this field is present
COD DOM (Code Domain Analyzer, IS-2000 only): marker controls
menu
