190 ICX (International) issued October 2000 ICX-50-700
Chapter 5. Key Telephone Features Section 700 - Operation
• Busy Override
• On-Hook VA
• The ability to receive a text message
• Silent Monitor
Hardware Requirements
•N/A
Related Programming
• FF1-0-03: Extension COS (Allow/deny Busy Override Send—Monitoring extension)
• FF1-2-02: Dial Plan at DT Pattern 1
• FF1-2-03: Dial Plan at DT Pattern 2
Considerations
• If the monitored extension is placed on-hook while Room Monitoring is activated, the
monitoring extension will hear a fast busy tone.
• If the monitoring extension goes on-hook while Room Monitoring is activated, the monitored
extension will remain in the monitored mode, and can be accessed by any other extension
allowed to access the room monitoring mode.
• A room cannot be monitored from more than one extension at a time. If an attempt is made to
monitor an extension while the extension is being monitored, the user will hear a fast busy tone.
• ISDN (s-point) extensions cannot access the Room Monitor feature in either the monitor or
monitored modes.
• A monitoring extension cannot forward a call on hold to a monitored extension.
• A monitored extension cannot receive a transferred call.
• If DND is enabled on either the monitoring or monitored extension, DND status is displayed on
the calling extension’s telephone.
• If the monitoring or monitored extension has an absence message set, the absence message will
be displayed on the calling extension’s telephone.
Silent Monitor
Version 4.0 and higher
Description
The Silent Monitor feature allows an ACD supervisor to monitor a call between an ACD agent and a
caller without the knowledge of either party. (See CAUTION, above.) If necessary, the ACD
supervisor can initiate a three-way call by barging into the call.
