Section 700 - Operation Chapter 5. Key Telephone Features
ICX-50-700 ICX (International) issued October 2000 197
To use a PSD Key that links multiple SSDs:
To manually link speed dial keys together:
Hardware Requirements
•N/A
Considerations
•N/A
Speed Dial Name Assignments
You can assign names to PSD numbers from a key telephone without entering the programming
mode. If allowed in the Extension Class of Service (COS), you can also assign names to SSD
numbers.
(PSD names can contain a maximum of 7 characters. SSD names can contain a maximum of 16
characters.)
4. Enter the PSD bin number (80-90). Enter Spd Dial displays
5. Press the MEMORY key.
6. Enter the SSD bin number (00-79 or 000-799) that contains
the first part of the number to be dialled.
7. Repeat steps 5-6 up to 5 more times for all additional SSDs
to be dialled.
8. Press the HOLD key when finished. Stored PSDXXX displays
Action Result
1. If necessary, select the trunk group (9 [UK/HK], 0 [Taiwan,
Malaysia, Indonesia], or 81-84). (Normally the trunk is
selected by the speed dial numbers.)
2. Press the PSD key.
Action Result
1. Lift the handset or press the ON/OFF key. Intercom dial tone
2. If necessary, access an outside line.
3. If you are using a PSD number, press the one-touch key for
the first part of the number.
If you are using an SSD number, press the MEMORY key,
then enter the SSD bin number.
4. Use the one-touch keys or press the MEMORY key and
enter the SSD codes to dial the parts of the phone number
until it is completed.
Action Result
